U.A.N.V.B.- SC "Raptor"

(Product Photos Coming soon)

Physical Specs

Housing Material: Carbon fiber reinforced thermoplastic composite

Structural Strength: Rivals 6061-T6 aluminum in tensile strength

Environmental Rating: Meets and exceeds IP68+ and MIL-STD-810H standards

Tube Compatibility: EGAC MX-11769, 3-pad MX-11769, or MX-10160 (with loss of gain)

Optics Compatibility: PVS-14 spec optics and accessories

Interchangeability: Image tube pod is interchangeable with the U.N.V.M. "Talon"

Electronic & Power Specs

Primary Power Source: Single CR123A battery (on-board)

Operation Time: 26+ hours of battery life

External Power Port: LEMO 00B 2-pin port

Manual Gain Control: Yes

IR Illuminator: Yes, with adjustable brightness and status indicator

Low Battery Indicator: Yes

Key Features

Single Control Knob: Controls power, gain, IR, and auto-off feature

Individual Pod Articulation: Pods power off individually when stowed

Tool-Free IPD: Toolless knobbed IPD stops included for rapid adjustment

Adjustable Pod Tension: User adjustable pod tension

Origin: Fully designed and assembled in the United States

Warranty: Lifetime repair or replacement on all housing components
