Nighthawk

Steele Industries Nighthawk-MG Night Vision Binocular

Physical Specs

Housing Weight: 6.5 oz (185 g)

Total Device Weight: 19.75 oz (560 g) with standard Mil-spec optics and battery

Dimensions: 4.5” L x 3.5” H x 4.5” W

Housing Material: Precision-machined 7075-T6 aerospace-grade aluminum

Articulation: Features dual articulating pods that fold flat against the helmet when stowed to reduce neck strain

Interpupillary (IPD) Adjustment: 55mm to 80mm via physical knobs for personalized alignment

User-Adjustable Tension: Pod resistance can be tightened or loosened by the operator via external screws

Environmental Rating: Submersible to 66ft (20m)

Durability: MIL-STD-810H water and drop-tested

Tube Compatibility: Fully compatible with both MX-10160 (Auto-gain) and MX-11769 (Manual gain) format tubes

Optics Compatibility: Fully compatible with all PVS-14 pattern eyepieces and objective lenses

Power Specs

Primary Power Source: (1) Onboard CR123 size battery

Operation Time: Approximately 25+ hours continuous runtime on a single Lithium battery

External Power Port: Integrated 4-pin LEMO-style port for connection to remote battery packs

Manual Gain Control: Dedicated knob allows for precise brightness adjustment of MX-11769 pigtail tubes

Automatic Pod Shutoff: Individual pods automatically power off when rotated into the stowed position

Integrated Indicators: Features onboard IR LED and Low Battery indicators

Onboard IR Illuminator: Built-in for use in zero-light environments

Key Features

Familiar Interface: Utilizes traditional PVS-14 style rotary controls (on/off/IR) to eliminate the need for operator retraining

Mission Ready: Robust full-metal construction designed specifically for professional duty and harsh field use

ISO Certified Assembly: Assembled in-house at Steele Industries using accredited ISO 9001:2015 processes and procedures

Warranty: 5 year system warranty with a Lifetime "no questions asked" warranty on the housing itself
