Thermal Sensor Specs

• Uncooled Infrared Sensor
• Pixel size: 12x12um
• Frame Rate: 50FPS

Digital Day/Night Vision Specs

• Frame Rate: 60Hz
• Resolution: 1920x1080 pixels
• Base Magnification: 5x
• Digital Magnification 5-20x
• IR Wavelength 850/940nm
• IR LRF Rating: Eye Safe, Class 3R

Display Specs

• Type: Micro-OLED


Power Specs

• External Power Supply: 5V Type-C USB


Hardware Specs

• Memory: 32GB
• IP Waterproof: IP67
• Operating Temp: -4 to 122F
• Recoil Rating: .50BMG
• WIFI & APP
• Onboard recording
• One shot zero

TNC225R Thermal Specs

• Resolution: 256x192 pixels
• NETD: ≤25mk @25℃
• Objective Lens Focal Length: 25mm
• Base Magnification: 3x
• Digital Magnification: 3-12x
• Field of View(HxV): 12.3yd@100yd x 9.2yd@100yd

TNC225R Digital Day/Night Vision Specs

• Video Record Resolution: 1024x768 pixels
• Field of View(HxV): 10.7yd@100yd x 6.0yd@100yd

Display Specs

• Resolution: 1024x768 pixels
• Frame Rate: 50Hz
• Operating Time: 5h
• Battery Type: 18650 Battery(flat top)
• Net Weight: 22.8oz
• Dimensions: 6.7x3.3x3.1 inches

TNC335R Thermal Specs

• Resolution: 384x288 pixels
• NETD: ≤18mk @25℃
• Objective Lens Focal Length:35mm
• Base Magnification: 2.5x
• Digital Magnification: 2.5-10x
• Field of View(HxV): 13.2yd@100yd x 9.9yd@100yd

TNC335R Digital Day/Night Vision Specs

• Video Record Resolution:1800x1080 pixels
• Field of View(HxV): 9.3yd@100yd x 5.2yd@100yd
• Display specs
• Resolution: 1920x1080 pixels
• Frame Rate: 60Hz
• Operating Time:6h
• Battery type: 21700 Battery(flat top)
• Net Weight: 25.6oz
• Dimensions: 9.2x3.2x3.0 inches

TNC635R Thermal Specs

• Resolution:640x512 pixels
• NETD:≤18mk @25℃
• Objective Lens Focal Length:35mm
• Base Magnification:1.5x
• Digital Magnification:1.5-6x
• Field of View(HxV): 21.9yd@100yd x 17.6yd@100yd

TNC635R  Digital Day/Night Vision specs

• Video Record Resolution:1800x1080 pixels
• Field of View(HxV): 9.3yd@100yd x 5.2yd@100yd

Display specs

• Resolution: 1920x1080 pixels
• Frame Rate: 60Hz
• Operating Time: 6h
• Battery type: 21700 Battery(flat top)
• Net Weight: 25.6oz
• Dimensions: 9.2x3.2x3.0 inches
• Net Weight: 13.7oz
• Dimensions: 7.9x2.7x2.0 inches
